8-54 ES User’s Guide
Hardkey/Softkey Reference
M
Softkey in the edit limit (min/max) menu. Use this key to set the
maximum limit for the marker limit function that is currently
highlighted in the on-screen table.
See “To Use Marker Limit Functions” on page 4-32 for more
information.
Access Keys:
Softkey in the marker search menu. Places the active marker at the
frequency point of maximum amplitude. If tracking is off, the marker
remains at that frequency. If tracking is on, the marker moves to the
maximum point with each sweep.
See “Using Markers” on page 4-3 for more information.
Access Keys:
Hardkey in the MEAS area. Turns on measurement channel 1 as the
active channel. Default mode is the S
11
measurement.
Hardkey in the MEAS area. Turns on measurement channel 2 as the
active channel. Default is measurement channel off; selecting it
changes setting to the most recent type of measurement made on this
channel, or, if not previously used, to the S
11
measurement.
Softkey in the annotation options menu. Allows you to toggle the
measurement channel annotation at the top of the display on or off.
See “Customizing the Display” on page 4-45 for more information.
Access Keys:
Softkey in the or menu. Turns the active
measurement channel off.
Softkey in several calibration menus. Measures a calibration standard
as part of your selected calibration procedure.
DISPLAY
MARKER
MEAS 1
MEAS 2
DISPLAY
MEAS 1 MEAS 2
