245
MLD messa
e Actions
Done
In response to a done message for an IPv6 multicast group, the proxy sends a multicast-
address-specific query for the group out the receiving port. After making sure that no
member port is contained in the forwarding entry for the IPv6 multicast group, the proxy
sends a done message for the group out all router ports.
Protocols and standards
RFC 4541, Considerations for Internet Group Management Protocol (IGMP) and Multicast Listener
Discovery (MLD) Snooping Switches
MLD snooping configuration task list
Complete these tasks to configure MLD snooping:
Task Remarks
Configuring basic functions of
MLD snooping
Enabling MLD snooping Required
Configuring the version of MLD snooping Optional
Configuring an IPv6 static multicast MAC address entry in
system view
Optional
Configuring MLD snooping port
functions
Configuring aging timers for dynamic ports Optional
Configuring static ports Optional
Configuring simulated joining Optional
Configuring fast-leave processing Optional
Disabling a port from becoming a dynamic router port Optional
Configuring MLD snooping
querier
Enabling MLD snooping querier Optional
Configuring MLD queries and responses Optional
Configuring source IPv6 addresses of MLD queries Optional
Configuring MLD snooping
proxying
Enabling MLD snooping proxying Optional
Configuring a source IPv6 address for the MLD messages
sent by the proxy
Optional
Configuring an MLD snooping
policy
Configuring an IPv6 multicast group filter Optional
Configuring IPv6 multicast source port filtering Optional
Configuring the function of dropping unknown IPv6
multicast data
Optional
Configuring MLD report suppression Optional
Configuring the maximum number of multicast groups that
a port can join
Optional
Configuring IPv6 multicast group replacement Optional
Configuring 802.1p precedence for MLD messages Optional
Configuring an IPv6 multicast user control policy Optional
