HP A5500 SI Switch Series User Manual

309
• Determine the ACL rule for IPv6 multicast group filtering
• Determine the maximum number of IPv6 multicast groups that can be joined on an interface
Enabling MLD
Enable MLD on the interface on which IPv6 multicast group memberships will be created and
maintained.
Follow these steps to enable MLD:
To do… Use the command… Remarks
Enter system view system-view —
Enable IPv6 multicast routing multicast ipv6 routing-enable
Required
Disable by default
Enter interface view interface interface-type interface-number —
Enable MLD mld enable
Required
Disabled by default
NOTE:
For more information about the multicast ipv6 routing-enable command, see the
IP Multicast
Command Reference
.
Configuring the MLD version
Because MLD message types and formats vary with MLD versions, the same MLD version should be
configured for all routers on the same subnet before MLD can work properly.
Configuring an MLD version globally
Follow these steps to configure an MLD version globally:
To do… Use the command… Remarks
Enter system view system-view —
Enter MLD view mld —
Configure an MLD version
globally
version version-number
Optional
MLDv1 by default
Configuring an MLD version on an interface
Follow these steps to configure an MLD version on an interface:
To do… Use the command… Remarks
Enter system view system-view —
Enter interface view
interface interface-type interface-
number
—
Configure an MLD version on the
interface
mld version version-number
Optional
MLDv1 by default

HP A5500 SI Switch Series Specifications

General

Layer Support	Layer 2 and Layer 3
MAC Address Table	16K entries
Routing Protocol	RIP, OSPF, BGP, IS-IS
Management	Web, CLI, SNMP
Input Voltage	100-240 V AC
Operating Temperature	0°C to 45°C
Ports	48 x 10/100/1000 ports, 4 x 10-Gigabit SFP+ ports
Dimensions	440 x 430 x 44 mm
Weight	5.5 kg
Operating Humidity	10% to 95% (non-condensing)
