HP BladeSystem c3000 Setup And Installation

Using the HP BladeSystem Insight Display 59
CAUTION: When calculating the Power Limit Watts AC value, derate the circuit to 80% of the
maximum to prevent tripping the circuit breaker (United States only).
CAUTION: If your facility cannot support the calculated peak Watts AC, set the Power Watts AC
value to match the capability of your facility.
Dynamic Power—The default setting is Enabled. The following selections are valid:
o Enabled—Some power supplies can be placed on standby to automatically increase overall
enclosure power subsystem efficiency.
o Disabled—All power supplies share the load. The power subsystem efficiency varies based on load.
OA1 IP Addr—The default setting is DHCP. If no IP address is received, the IP address is 0.0.0.0. The
IP address, mask, and gateway are set within this option.
OA2 IP Addr—If this module is present, the default setting is DHCP. If no IP address is received, the IP
address is 0.0.0.0. If only one Onboard Administrator module is installed, the screen will display "Not
Present."
Enclosure Name—The default setting is a unique factory-assigned name. The accepted character values
are 0–9, A–Z, a–z, -, _ and . is used to signal the end of the name.
NOTE: Do not use the symbol in the middle of a text field. Entries in text fields will be
truncated to the last character before the symbol.
TIP: Select Clear from the navigation bar to quickly clear entries in text fields up to the
symbol.
Rack Name—The default setting is UnnamedRack The accepted character values are 0–9, A–Z, a–z, -,
_ and . is used to signal the end of the name.
DVD Drive—The default setting is Disconnected on all blades. The DVD Connect Status menu displays
the current DVD connection status with an icon.
Select a DVD icon on the DVD Connect menu to navigate to the Blade DVD Connection menu.
