Memory Modules
Hardware and Software Guide 8–4
9. Insert the new memory module:
a. Align the tabbed (notched) edge 1 of the module with the
tabbed area in the memory slot.
b. With the module at a 45-degree angle from the surface of
the memory compartment, press the module into the
memory slot until it is seated 2.
