Component ID
Hardware and Software Guide 1–13
Bottom Components
The following illustration and table identify and describe the
components on the bottom of the notebook
.
Component Description
1
Primary battery bay Holds the primary battery pack.
2
Primary battery locking latch Secures the primary battery pack into
the battery bay.
3
Travel battery connector Connects an optional travel battery.
4
Business card holder Holds a standard size business card.
5
Expansion memory module
compartment
Accepts one optional memory module.
6
Hard drive bay Holds the primary hard drive.
(Continued)
