4. Select the percentage of change from –100% to +100%. To correct light banding, decrease the percentage.
To correct dark banding, increase the percentage.
5.
Tap on the front panel to return to the all-apps page.
Return to default calibration
Returning to the default calibration sets all the corrections made by the paper advance calibration to zero. To
return to the default paper advance calibration value, you must reset the calibration.
1.
From the front panel, tap , then , then Reset calibration.
2. Wait until the front panel displays the operation has completed successfully.
ENWW Recalibrate the paper advance 129

HP DesignJet T1700dr Specifications

General

Color	Yes
Printing colors	Cyan, Grey, Magenta, Matte black, Photo black, Yellow
Print technology	Thermal inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	6
Page description languages	HP-GL/2, PDF 1.7, PostScript 3, TIFF, URF
Print speed (normal quality, A1)	116 pph
Accuracy	0.1 %
Media thickness	0.8 mm
Roll top margin	3 mm
Maximum print size	1118 x 1676 mm
ISO A-series sizes (A0...A9)	A0, A1, A2, A3, A4
Wi-Fi	-
USB 2.0 ports quantity	0
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Sustainability certificates	ENERGY STAR
Package depth	770 mm
Package width	1955 mm
Package height	710 mm
Package weight	128000 g
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Power consumption (off)	0.1 W
Power consumption (standby)	24 W
Power consumption (typical)	100 W
Storage media	HDD
Internal storage capacity	500 GB
Sound power level (standby)	5 dB

Weight and Dimensions

Depth	695 mm
Width	1802 mm
Height	998 mm
