6. Select the Device and Document Settings tab, and click the Custom Properties button.
7. In the Paper/Quality tab, select the paper type that you intend to use.
NOTE: If you select neither the paper source nor the paper type, the printer will not print on any protected
roll (see Roll protection on page 59).
8. Select the print quality (your own choice between speed and quality of printing).
9. If you intend to print on roll paper, you must decide where the printer should cut the paper. Click the
Margins/Cutter Settings button and select Clip contents by margins. You can also adjust the crop lines,
which indicated where to cut the paper after printing.
10. Select the Layout/Output tab, then select the Autorotate option. Autorotation can help to avoid wasting
paper.
11. Click the OK button and save your conguration changes to a PC3 le.
12. When you have clicked the OK button in the Plot window, the printer will construct a print preview.
ENWW Print a project 87
