Item LED Status Definition
Flashing green
The drive is doing one of the following:
• Rebuilding
• Performing a RAID migration
• Performing a stripe size migration
• Performing a capacity expansion
• Performing a logical drive extension
• Erasing
Flashing amber/
green
The drive is a member of one or more logical drives and predicts the drive will fail.
Flashing amber The drive is not configured and predicts the drive will fail.
Solid amber The drive has failed.
O The drive is not configured by a RAID controller.
4 Do not
remove
Solid white Do not remove the drive. The drive must be ejected from the PCIe bus prior to
removal.
Flashing white The drive ejection request is pending.
O The drive has been ejected.
5 Power Solid green Do not remove the drive. The drive must be ejected from the PCIe bus prior to
removal.
Flashing green The drive ejection request is pending.
O The drive has been ejected.
NVMe SSD button actions
Component identification
127
