To replace the component, reverse the removal procedure.
Removing and replacing a DIMM guard
Prerequisites
Before you perform this procedure, make sure that you have a T-15 Torx screwdriver available.
Procedure
1.
If installed,
remove the bezel.
2.
Power down the server.
3.
Remove all power:
a.
Disconnect each power cord from the power source.
b.
Disconnect each power cord from the server.
4.
Do one of the following:
•
Extend the server from the rack.
•
Remove the server from the rack.
5. Remove the access panel.
6. If replacing the left DIMM guard,
remove the chassis intrusion detection switch.
7. Remove the DIMM guard.
• Right DIMM guard
Removal and replacement procedures
83
