To replace the component, reverse the removal procedure.
Removing and replacing the Pensando DSP DSC-25 2p SFP28 card
with the iLO Sideband ALOM Module
Decommissioning the Pensando DSP DSC-25 2p SFP28 card
Procedure
Before removing the DSC-25 card from the server, you must first decommission the card using the Pensando Policy and
Services Manager (PSM).
For more information, see Pensando Distributed Services Card for Single-Wire Management (DSC-25-SWM) Removal/
Replacement Guide on the Hewlett Packard Enterprise website (https://www.hpe.com/support/dsc25-replacement).
Removing and replacing the Pensando DSP DSC-25 2p SFP28 card
IMPORTANT: Before beginning this procedure, follow the
warnings and cautions.
Prerequisites
Before you perform this procedure, make sure that you have the following items available:
• The components included with the hardware option kit
• T-15 Torx screwdriver
Procedure
1. If installed,
remove the bezel.
2. Power down the server.
3. Remove all power:
Removal and replacement procedures
73
