a. Disconnect each power cord from the power source.
b. Disconnect each power cord from the server.
4. Do one of the following:
• Extend the server from the rack.
• Remove the server from the rack.
5. Remove the access panel.
6. If the Pensando DSP iLO Sideband ALOM Module is installed, disconnect the auxiliary cable from the DSC-25 card.
7.
If replacing the DSC-25 card on the primary riser board, remove the primary riser cage.
8.
Remove the DSC-25 card.
• Primary riser slot 1
• Primary riser slot 2
Removal and replacement procedures
74
