To replace the component, reverse the removal procedure.
Removing and replacing the iLO Service Port assembly in SFF
Prerequisites
Before you perform this procedure, make sure that you have a T-15 Torx screwdriver available.
Procedure
1.
If installed,
remove the bezel.
2.
Power down the server.
3.
Remove all power:
a.
Disconnect each power cord from the power source
b.
Disconnect each power cord from the server.
4.
Do one of the following:
•
Extend the server from the rack.
•
Remove the server from the rack.
5. Remove the access panel.
6.
Remove the SFF front I/O assembly.
7. Remove the iLO Service Port assembly in SFF.
a. Remove one T-15 screw.
b. Remove the iLO Service Port assembly.
Removal and replacement procedures
