To replace the component, reverse the removal procedure.
Removing and replacing the USB 3.0 cable assembly in LFF
Prerequisites
Before you perform this procedure, make sure that you have a T-15 screwdriver available.
Procedure
1.
If installed,
remove the bezel.
2.
Power down the server.
3.
Remove all power:
a.
Disconnect each power cord from the power source
b.
Disconnect each power cord from the server.
4.
Do one of the following:
•
Extend the server from the rack.
•
Remove the server from the rack.
5. Remove the access panel.
6. Disconnect the USB
30 cable from the system board.
7. Release the cable from clips.
8. Remove the USB 30 cable assembly.
Removal and replacement procedures
71
