To replace the component, reverse the removal procedure.
Removing and replacing the FlexibleLOM adapter
Prerequisites
Before you perform this procedure, make sure that you have a T-10 Torx screwdriver available.
Procedure
1.
If installed,
remove the bezel.
2.
Power down the server.
3.
Remove all power:
a.
Disconnect each power cord from the power source.
b.
Disconnect each power cord from the server.
4.
Do one of the following:
•
Extend the server from the rack.
•
Remove the server from the rack.
5. Remove the access panel.
6.
Remove the primary riser cage.
7. Disconnect all cables from the FlexibleLOM adapter.
8. Remove the FlexibleLOM adapter.
Removal and replacement procedures
72
