Removing and replacing the secondary riser blank
Prerequisites
Before you perform this procedure, make sure that you have T-15 Torx screwdriver available.
Procedure
1. If installed, remove the bezel.
2.
Power down the server.
3. Remove all power:
a. Disconnect each power cord from the power source.
b. Disconnect each power cord from the server.
4. Do one of the following:
• Extend the server from the rack.
• Remove the server from the rack.
5.
Remove the access panel.
6.
Remove the secondary riser blank.
To replace the component, reverse the removal procedure.
Removing and replacing a riser board
Prerequisites
If replacing the primary riser board, make sure that you have a T-15 Torx screwdriver available.
Removal and replacement procedures
