c. Place the heatsink on a flat work surface with its contact side facing upward.
9.
Use an alcohol wipe to remove the existing thermal grease from the heatsink.
Allow the alcohol to evaporate before continuing.
10.
Use a T-20 Torx screwdriver to loosen the three captive screws in the sequence shown in the following image, and
then pivot the force frame upward.
11.
Remove the processor:
a.
Hold the lift tabs near the front end of the rail frame, and then pivot the rail frame to the vertical position.
b.
Slide the processor out of the rail frame.
Removal and replacement procedures
90
