Chapter 3
Upgrade Procedures for 1.5 GHz (A9731A) or 1.6 GHz (A9732A, or A9733A) Processors
Introduction
44
Prior to installing a processor into your system, read the following instructions carefully and refer to
Figure 3-3, “Installing Processor on Extender Board,” for a complete understanding of this process.
Step 1. Ensure the cam on the processor socket lock is in the unlocked, counterclockwise position.
Step 2. Carefully lower the processor, without the sequencer clamp, onto the processor socket. Align the
pins on the bottom of the heatsink to the slots in the retention frame on the extender board.
CAUTION Test the alignment of the assembly to the socket by gently moving the assembly back
and forth with the palm of your hand—you should feel little or no sideplay. However,
because the assembly is not yet tightened, it may tilt slightly towards the center of
the extender board—this is acceptable.
CAUTION Before locking the processor assembly into its socket, ensure that the power cable is
not pinched between the heatsink and sheet metal frame of the extender board. Also,
ensure that the two power cable ends attached to the CPU assembly do not come
