HP Integrity rx4640 Upgrade Guide

Chapter 6
Removing and Replacing Core I/O Cards
Remove and Replace the SCSI Core I/O Card
85
Remove and Replace the SCSI Core I/O Card
The hp Integrity rx4640 Server has two I/O card slots that are dedicated for core I/O cards.
PCI Slot Locations and Configurations
PCI slots are numbered from 1 through 8 in your HP Server. See Figure 6-7, “Slot ID Numbering.” The
dedicated core I/O card slots are slots 1 and 2.
The following describes configuration requirements for slots 1 and 2:
• PCI slot 1 is dedicated for use by a SCSI HBA card. Slot 1 is not hot-plug capable. Additional PCI
expansion cards may not be placed in slot 1.
• PCI slot 2 is dedicated for use a LAN card. Slot 2 is not hot-plug capable. Additional PCI expansion cards
may not be placed in slot 2.
Figure 6-7 Slot ID Numbering
Slot ID Number
1 2345678
Core I/O
PCI
Public I/O PCI
