Chapter 4
Memory Extender Board Upgrade Procedures
Introduction
57
Table 4-2 DIMM Filler Requirements for 32 DIMM Extender Board
32 DIMM Extender Board
DIMMs Loaded
Fillers required
a
a. One DIMM filler board covers two DIMM adjacent slots.
4 DIMMs in quad 0 12 fillers total:
2 fillers in quads 1, 3, 4, 5, 6, and 7
(quad 2 remains unfilled)
8 DIMMs in quads 0 and 1 8 fillers total:
2 fillers in quads 4, 5, 6, and 7
(quads 2 and 3 remain unfilled)
12 DIMMs in quads 0, 1, and 2 8 fillers total:
2 fillers in quads 4, 5, 6, and 7
(quad 3 remains unfilled)
16 DIMMs in quads 0, 1, 2, and 3 8 fillers total:
2 fillers in quads 4, 5, 6, and 7
(all quads filled)
20 DIMMs in quads 0, 1, 2, 3, and 4 4 fillers total:
2 fillers in quads 5, 7
quad 6 remains unfilled
24 DIMMs in quads 0, 1, 2, 3, 4, and 5 No fillers required
28 DIMMs in quads 0, 1, 2, 3, 4, 5, and 6 No fillers required
32 DIMMs in quads 0, 1, 2, 3, 4, 5, 6, and 7 No fillers required
