HP LaserJet P2015 Series

Table 8-6 Internal components (1 of 4)
Ref Description Part number Qty
1 Roller, face-down RL1-0527-000 1
2 Paper pick-up gear assembly RM1-1301-000 1
3 Paper-feed guide assembly RM1-4263-000 1
4 Bushing, right RB2-2895-000 1
5 Bushing, left RB2-2896-000 1
6 Bushing RB2-2897-000 1
7 Shaft, paper pick-up drive RC1-3471-000 1
8 Flag, paper-sensing RC1-3472-000 1
9 Roller, idler RC1-3481-000 2
10 Arm, idler roller RC1-3482-000 2
11 Flag, M.P. sensor RC2-0415-000 1
12 Base, separation pad RC2-0419-000 1
13 Spring, compression RU5-2323-000 2
14 Spring compression RU5-2894-000 1
15 Spring, tension RU5-2898-000 1
16 M.P. sensor PCB assembly RM1-4162-000 1
17 Holder, M.P. sensor RC2-0414-000 1
18 Screw, tap, binding head, M3x8 XB4-7300-809 1
19 Roller, paper pickup idler RC1-3470-000 2
20 Roller, paper pick-up RL1-0540-000 1
21 Pad, M.P. separation RL1-1524-000 1
22 Paper-retaining assembly (HP LJ P2015d, P2015dn, and
P2015x)
RM1-4265-000 1
23 Paper retaining assembly (HP LJ P2015) RM1-4276-000 1
24 Bushing RC1-3665-000 2
25 Link, gear release RC1-3668-000 1
26 Gear, 29T RU5-0331-000 1
27 Gear, 19T RU5-0332-000 1
28 Guide, cable RC2-1569-000 1
29 Guide, reverse RC2-0323-000 1
30 Screw, RS, M3x6 XA9-1495-000 7
31 Screw, tap, M3x6 XA9-1503-000 6
32 Screw, RS, M3x8 XA9-1504-000 1
33 Screw, tapping, truss head, M4x10 XB4-7401-005 1
ENWW Internal assemblies 199
