Internal components
Figure 5-2 Cross-section of printer on page 71 highlights the major internal components.
Figure 5-2 Cross-section of printer
1 Top output bin delivery roller
2 Fuser film
3 Laser/scanner
4 Primary charging roller
5 Developer roller
6 Print cartridge
7 Feed roller
8 Multipurpose pickup roller
9 Multipurpose separation pad
10 Separation pad
ENWW Internal components 71
