HP LaserJet P2015 Series

Table 8-7 Internal components (2 of 4)
Ref Description Part number Qty
1 Guide, cartridge, right lower RC2-0346-000 1
2 Duct RC2-0351-000 1
3 Guide, cable RC2-0397-000 1
4 Cam RC2-0410-000 1
5 Guide, cassette, right rear RC2-0416-000 1
6 Guide, cartridge, right upper RC2-0426-000 1
7 Guide, shutter, front RC2-0428-000 1
8 Guide, cassette, right center 1 RC1-3456-000 1
9 Guide, cassette, right center 2 RC1-3457-000 1
10 Guide, shutter, rear RC1-3535-000 1
11 Holder, switch RC1-3727-000 1
12 Screw, RS, M3x8 XA9-1504-000 8
13 Screw, RS, M3x6 (HP LJ P2015d, P2015dn, and P2015x) XA9-1495-000 10
13 Screw, RS, M3x6 (HP LJ P2015) XA9-1495-000 7
14 Screw, RS, M3x6 XA9-1561-000 1
15 Screw, toothed washer, M4x6 XB2-7400-606 1
16 Motor, DC RK2-1567-000 1
17 Guide, cassette, right front RL1-0517-000 1
18 Inlet/switch cable assembly RM1-4169-000 1
19 Scanner assembly RM1-4262-000 1
20 Plate, solenoid holder RC1-3459-000 1
21 Cam, right RC1-3546-000 1
22 Stopper RC1-3580-000 1
23 Duplex driver PCB assembly (HP LJ P2015d, P2015dn, and
P2015x)
RM1-1262-000 1
24 Spring, compression RU5-2335-000 1
25 Shield, duplexing solenoid (HP LJ P2015d, P2015dn, and
P2015x)
RC2-0347-000 1
26 Plate, grounding RC2-1568-000 1
27 Arm, cam RC2-0405-000 1
28 Arm, link RC2-0406-000 1
29 Holder, fan RC2-0349-000 1
30 Arm, tag RC2-0392-000 1
31 Duct RC2-0354-000 1
32 Holder, drawer connector RC2-0396-000 1
ENWW Internal assemblies 201
