HP LaserJet P2015 Series

Table 8-8 Internal components (3 of 4)
Ref Description Part number Qty
1 Cover, drum RC1-3563-000 1
2 Plate, drum grounding RC1-3565-000 1
3 Plate, transfer grounding RC1-3698-000 1
4 Spring, grounding RC1-3700-000 1
5 Spring, transfer, right RC1-3702-000 1
6 Cover, registration gear RC1-3708-000 1
7 Screw, tapping, truss head, M4x10 XB4-7401-005 7
8 Spring, compression RC1-3736-000 1
9 Spring, contact RC2-0344-000 1
10 Bushing RC2-0356-000 1
11 Bushing RC2-0357-000 1
12 Eliminator, static charge RC2-0358-000 1
13 Guide, transfer front RC2-0359-000 1
14 Roller, transfer RM1-4279-000 1
15 Plate, registration grounding RC2-0384-000 1
16 Gear, 33T RU5-0320-000 1
17 Spring, compression RU5-2144-000 1
18 Spring, compression RU5-2338-000 1
19 Screw, with washer, M3x8 XA9-1420-000 1
20 Screw, with washer, M4x12 XA9-1422-000 1
21 Screw, tap, binding head, M3x8 XB4-7300-809 2
22 Sheet, registration damper RC1-3695-000 1
23 Top sensor assembly RM1-1283-000 1
24 Paper-width sensor assembly RM1-4245-000 1
25 Registration assembly RM1-4244-000 1
26 Screw, RS, M3x8 XA9-1504-000 1
27 Shutter link assembly RM1-1321-000 1
28 Label, transfer guide open RC1-3796-000 1
29 Paper-sensor PCB assembly RM1-4159-000 1
ENWW Internal assemblies 205
