HP LaserJet P2015 Series

Table 8-9 Internal components (4 of 4)
Ref Description Part number Qty
1 Roller, M.P. paper pick-up RL1-1525-000 1
2 Side plate, M.P. drive RL1-1531-000 1
3 Guide, cassette, left center 1 RC1-3461-000 1
4 Guide, cassette, left center 2 RC1-3462-000 1
5 Guide, cassette, left rear RC1-3463-000 1
6 Lever, cartridge contact RC1-3542-000 1
7 Spring, torsion RC1-3543-000 1
8 Spring, contact RC1-3719-000 1
9 Guide, cartridge, left lower RC2-0339-000 1
10 Holder contact RC2-0342-000 1
11 Guide, F.F.C RC2-0423-000 1
12 Sheet, plate bottom RC2-1578-000 1
13 Guide, cassette, left front RL1-0518-000 1
14 Paper pick-up gear assembly RM1-4275-000 1
15 Plate, drum grounding RC1-3541-000 1
16 Arm lock RC1-3561-000 1
17 Bushing RC1-3562-000 1
18 Roller RC1-0950-000 2
19 Spring, compression RU5-2337-000 1
20 Gear, 19T RU5-0927-000 1
21 Gear, 26T RU5-0928-000 1
22 Gear, 14T RU5-0929-000 1
23 Holder, M.P. solenoid RC2-0334-000 1
24 Guide, cartridge font RC2-0340-000 1
25 Guide, M.P. cable RC2-0335-000 1
26 Guide, cartridge, left upper RC2-0425-000 1
27 Spring, torsion RC2-0427-000 1
28 Guide, F.F.C RC2-0424-000 1
29 Spring, grounding RC1-0944-000 1
30 Holder, paper pick-up roller RC2-0386-000 1
31 Cam, M.P., left RC2-0387-000 1
32 Cam, M.P., right RC2-0388-000 1
33 Cover, paper pick-up roller RC2-0420-000 1
34 Microswitch RK2-0534-000 1
ENWW Internal assemblies 207
