HP LaserJet P2015 Series

Table 8-15 Cassette assembly
Ref Description Part number Qty
Cassette RM1-4251-000 1
1 Cassette body assembly RC1-3483-000 1
2 Cassette cover assembly RM1-4252-000 1
3 Back end limit assembly RM1-1295-000 1
4 Plate, lifter RL1-0522-000 1
5 Left paper side-end assembly RM1-1296-000 1
6 Right paper side-end assembly RM1-1297-020 1
7 Separation pad assembly RM1-1298-000 1
8 Screw, M4x10 XB4-7401-005 2
9 Spring, compression RC1-3489-000 2
10 Gear, 10T RU5-0328-000 1
11 Spring, grounding RC1-3492-000 1
12 Spring, tension RU5-2324-000 1
13 Lock, lifter plate RC1-3490-000 1
14 Stopper, claw RC1-4198-000 2
15 Stopper, cassette left RC1-3508-000 1
16 Spring, compression RU5-2327-000 2
17 Stopper, cassette right RC1-3507-000 1
ENWW Internal assemblies 223
