HP StorageWorks 8/20q Command Line Interface Guide

HP StorageWorks 8/20q Fibre Channel Switch Command Line Interface Guide 41
Hardware information
To display the status of the switch hardware, including fans, power supplies, internal temperature, and
Heartbeat LED status, enter the show chassis command.
The following is an example of the show chassis command:
8/20q FC Switch #> show chassis
Chassis Information
-------------------
BoardTemp (1) - Degrees Celsius 26
BoardTemp (2) - Degrees Celsius 31
BoardTemp (3) - Degrees Celsius 31
PowerSupplyStatus (1) Good
HeartBeatCode 1
HeartBeatStatus Normal
The HeartBeatCode and HeartBeatStatus entries indicate the power-on self test (POST) results
revealed by the Heartbeat LED blink patterns. The result is normal operation or a blink pattern indicating a
critical error as described in Table 3. For information about Heartbeat LED blink patterns, see the HP
StorageWorks 8/20q Fibre Channel Switch Installation and Reference Guide.
Firmware information
To display a summary of switch identity information, including the firmware version, enter the
show version command. The following is an example of the show version command:
8/20q FC Switch #> show version
*****************************************************
* *
* Command Line Interface SHell (CLISH) *
* *
*****************************************************
SystemDescription HP StorageWorks 8/20q Fibre Channel Switch
HostName <undefined>
EthIPv4NetworkAddress 10.20.11.192
EthIPv6NetworkAddress ::
MACAddress 00:c0:dd:00:71:ee
WorldWideName 10:00:00:c0:dd:00:71:ed
SerialNumber FAM033100024
SymbolicName 8/20q FC Switch
ActiveSWVersion V8.0.4.xx.xx
ActiveTimestamp day month date time year
POSTStatus Passed
LicensedPorts 20
SwitchMode Full Fabric
Table 3 Heartbeat LED activity
HeartBeatCode–HeartBeatStatus Description
1-Normal One blink per second–Normal operation
2-AppDied Two blink cluster–Internal firmware failure
3-PostFailed Three blink cluster–Fatal POST error
4-CorruptFilesystem Four blink cluster–Configuration file system error
5-Overheating Five blink cluster– Over temperature
