1 Access panel 2 Fan cage
3 PCI riser 4 Drive cage
5 DIMMs 6 Heatsink
7 Processor 8 Power supply
9 System board assembly 10 Hard drive
11 Fan
For a rear view drawing of the HPE StoreOnce 3500 Series, see Figure 5.
HPE StoreOnce 5100 System Components
The HPE StoreOnce 5100 System is based on an HPE ProLiant DL380 Gen9 server. It has a base
configuration of 12 LFF disks for data storage and two disks for the operating system. Up to five 48 TB
Capacity Upgrade Kits may be connected to the base unit, each requires a separate license.
Optional hardware – 10GbE Network cards, FC cards, and SFP transceivers – are not part of the basic
configuration.
The following table lists Spares Part Numbers for the main components in the head server. See HPE
StoreOnce 5100 System Capacity Upgrade Kit Components on page 15 for information about
components in the storage enclosure.
NOTE:
This list is an offline list, created from partsurfer. If there is a problem with these Spares Part Numbers,
check the online source at: http://partsurfer.hpe.com/search.aspx. If the problem exists in the online
source, use the feedback form to log the problem: http://partsurfer.hpe.com/ContactUs.aspx.
Table 4: HPE StoreOnce 5100 System, BB915A
Part Spares Part Number Description Hot plug
OS Hard disk drive
(900GB)
653971-001 SPS-DRV HD 900GB 6G
SAS 10K 2.5 DP EN SC
Yes
Hard disk drive (4 TB) 695842-001 SPS-DRV HD 4TB 3.5
7.2K 6G SAS SC MDL
Yes
SmartArray RAID
Controller
749796-001 SPS-BD AROC P440ar
Cntrlr
No
SmartArray Battery Pack 815983-001 SPS-BATT PACK
ENHANCED MegaCell
96W
No
Power supply 754381-001 SPS-PS 800W FS
PlatinumPlus
Yes
Table Continued
12 HPE StoreOnce 5100 System Components
