Table 12: I/O module status LEDs
Indicator Display Description
7–segment display On Indicates the enclosure number or
an error/warning code
Data ports (DP-1, DP-2) Green on, amber off Link at high speed with no activity
Green flashing, amber off Link at high speed with activity
Green on, amber on Link at low speed with no activity
Green flashing, amber on Link at low speed with activity
Green off, amber on No link or no cable connected
Green flashing, amber flashing Location requested
I/O module status LED Green on, amber off Normal operation
Green flashing, amber off Shutdown in progress, no fault
Green off, amber on Fault
Green flashing, amber on Shutdown in progress, fault
Green on, amber flashing Predictive failure
Green flashing, amber flashing Shutdown in progress, predictive
failure
Locate UID Off Normal operation
Blue on Location requested. Safe to
remove.
Blue flashing Location requested. Do not
remove. Indicates that
maintenance is in progress. For
example, firmware updating.
HPE StoreOnce 5100 System expansion shelf error messages
Most error messages are reported in the StoreOnce GUI or CLI with appropriate diagnostic messages.
However, there are a few instances where problems are not explicitly recorded and it is necessary to check
the 7-segment display on the rear of the expansion shelf to identify the error code. Press the System Locate
UID button to display the error code.
This section contains a full list of error conditions.
32 HPE StoreOnce 5100 System expansion shelf error messages
To Next Page
