7 Heatsink 8 Processor
9 DIMM 10 System I/O board
11 Fan 12 Drive
HPE StoreOnce 3500 Series Components
The HPE StoreOnce 3520 System and HPE StoreOnce 3540 System are based on an HPE ProLiant DL380
Gen9 server. Both models have a base configuration of 12 LFF disks, with basic storage capacity capped at
50% of the available usable capacity. A license is required to make the full storage capacity available for use.
Optional hardware — 10GbE Network cards, FC cards, and SFP transceivers are not part of the basic
configuration.
The following table lists Spares Part Numbers for the main components in the server unit.
NOTE:
This list is an offline list, created from partsurfer. If there is a problem with these Spares Part Numbers,
check the online source at: http://partsurfer.hpe.com/search.aspx. If the problem exists in the online
source, use the feedback form to log the problem: http://partsurfer.hpe.com/ContactUs.aspx.
Table 3: HPE StoreOnce 3500 Series, BB914A and BB922A
Part Spares Part Number Description Hot plug
Hard disk drive (2 TB,
3520)
653948-001 SPS-DRV HD 2TB 6G
SAS 7.2K 3.5 DP MDL
SC
Yes
Hard disk drive (4 TB,
3540)
695842-001 SPS-DRV HD 4TB 3.5
7.2K 6G SAS SC MDL
Yes
Power supply 754381-001 SPS-PS 800W FS
PlatinumPlus
Yes
Processor 762445-001 SPS-PRO E5-2620v3 6C
2.4GHz 85W
No
Memory DIMM 774172-001 SPS-MEMORY DIMM
16GB 2Rx4
PC4-2133R-15
No
System board 775400-001 SPS-PCA dl380/dl360
Gen9 SYS I/O
No
PCIe riser card 1 PCA
(for PCIe slots 1 to 3)
777281-001 SPS-PCA dl380 3-S x8
PCI-E Riser
No
PCIe riser card 2 PCA
(for PCIe slots 4 to 6)
777283-001 SPS-PCA dl380 3-S 2
x16 x8 PCI-E riser2
No
Table Continued
HPE StoreOnce 3500 Series Components 9
