15 1Gb RJ45 Port 2 16 1Gb RJ45 Port 1 (eth0)
17 iLO4 connector 18 USB connectors
19 Rear UID LED
HPE StoreOnce 5100 System Capacity Upgrade Kit
Components
The HPE StoreOnce 5100 System (48 TB) Capacity Upgrade Kit (BB916A) is a 2U disk enclosure containing
twelve 4 TB disks. It includes a hot spare disk. The StoreOnce configuration has a single I/O module (in the
top location) plus a “blank” module.
The following table lists Spares Part Numbers for the main components in the storage enclosure.
NOTE:
This list is an offline list, created from partsurfer. If there is a problem with these Spares Part Numbers,
check the online source at: http://partsurfer.hpe.com/search.aspx. If the problem exists in the online
source, use the feedback form to log the problem: http://partsurfer.hpe.com/ContactUs.aspx.
Table 5: HPE StoreOnce Capacity Upgrade, BB916A
Part Spares Part Number Description Hot plug?
Enclosure backplane 832031-001* SPS-PCA Backplane LFF
HDD (1-based/IOM)
No*
Hard disk cage 781531-001 SPS Cage; LFF Hard
Disk Drive (HDD)
No
Fan assembly 781532-001 SPS Fan Assembly Yes
I/O module 781867-001* SPS I/O Module; LFF 2
Port
No*
Power distribution board 808276-001 SPS-VRM Assy No
Power supply 536404-001 SPS-PWR SUPPLY,
460W,12V,HTPLG,RED
Yes
Rail kit 700520-001 SPS-RAIL KIT 2U No
HDD, hard disk drive 844894-001 SPS-DRV HD 4TB 3.5
7.2K 6G SAS QR MDL
Yes
Fan control card cable 740127-001 SPS - Fan interconnect
cable
No
Table Continued
HPE StoreOnce 5100 System Capacity Upgrade Kit Components 15
