171
Step Command Remarks
2. Create a remote destination
group.
mirroring-group
group-id
remote-destination
By default, no remote destination
group exists on a device.
Configuring the monitor port for a remote destination group
To configure the monitor port for a mirroring group, use one of the following methods:
• Configure the monitor port for the mirroring group in system view.
• Assign a port to the mirroring group as the monitor port in interface view.
When you configure the monitor port for a remote destination group, follow these restrictions and
guidelines:
• Do not enable the spanning tree feature on the monitor port.
• Use a monitor port only for port mirroring, so the data monitoring device receives only the
mirrored traffic.
• A mirroring group must contain only one monitor port.
• A monitor port can belong to only one mirroring group.
Configuring the monitor port for a remote destination group in system view
Step Command Remarks
1. Enter system view.
system-view
N/A
2. Configure the monitor port
for the specified remote
destination group.
mirroring-group
group-id
monitor-port
interface-type
interface-number
By default, no monitor port is
configured for a remote
destination group.
Configuring the monitor port for a remote destination group in interface view
Step Command Remarks
1. Enter system view.
system-view
N/A
2. Enter interface view.
interface
interface-type
interface-number
N/A
3. Configure the port as the
monitor port for the specified
remote destination group.
mirroring-group
group-id
monitor-port
By default, a port does not act as
the monitor port for any remote
destination group.
Configuring the remote probe VLAN for a remote destination group
When you configure the remote probe VLAN for a remote destination group, follow these restrictions
and guidelines:
• Only an existing static VLAN can be configured as a remote probe VLAN.
• When a VLAN is configured as a remote probe VLAN, use the remote probe VLAN for port
mirroring exclusively.
• Configure the same remote probe VLAN for the remote groups on the source and destination
devices.
To configure the remote probe VLAN for a remote destination group:
