HPE FlexFabric 5700 Series User Manual

172
Step Command Remarks
1. Enter system view.
system-view
N/A
2. Configure the remote probe
VLAN for the specified
remote destination group.
mirroring-group
group-id
remote-probe vlan
vlan-id
By default, no remote probe VLAN
is configured for a remote
destination group.
Assigning the monitor port to the remote probe VLAN
Step Command Remarks
1. Enter system view.
system-view
N/A
2. Enter the interface view of
the monitor port.
interface
interface-type
interface-number
N/A
3. Assign the port to the
remote probe VLAN.
• For an access port:
port access vlan vlan-id
• For a trunk port:
port trunk permit vlan vlan-id
• For a hybrid port:
port hybrid vlan vlan-id { tagged |
untagged }
For more information about the
port access vlan
,
port trunk
permit vlan
, and
port hybrid
vlan
commands, see Layer
2—LAN Switching Command
Reference.
Configuring a remote source group on the source device
Creating a remote source group
Step Command Remarks
1. Enter system view.
system-view
N/A
2. Create a remote source
group.
mirroring-group
group-id
remote-source
By default, no remote source
group exists on a device.
Configuring source ports for a remote source group
To configure source ports for a mirroring group, use one of the following methods:
• Assign a list of source ports to the mirroring group in system view.
• Assign a port to the mirroring group as a source port in interface view.
To assign multiple ports to the remote source group as source ports in interface view, repeat the
operation.
When you configure source ports for a remote source group, follow these restrictions and guidelines:
• Do not assign a source port of a remote source group to the remote probe VLAN of the remote
source group.
• A mirroring group can contain multiple source ports.
• A port can act as a source port for multiple mirroring groups.
• A source port cannot be used as a reflector port, monitor port, or egress port.
• When you configure a TRILL access port as a source port, only non-TRILL-encapsulated
packets can be mirrored. Other packets are dropped.
• When you configure a TRILL trunk port as a source port, only TRILL-encapsulated packets can
be mirrored. Other packets are dropped.

HPE FlexFabric 5700 Series Specifications

General

Product Line	HPE FlexFabric
Model	5700 Series
Power Supply	Redundant power supply options
Layer Support	Layer 2/3
Management	HPE Intelligent Management Center (IMC), CLI, SNMP
Routing Protocol	RIP, OSPF, BGP, IS-IS
Features	Virtualization
Compliant Standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1w, IEEE 802.1s, IEEE 802.3ad, IEEE 802.3ae
Operating Temperature	32°F to 113°F (0°C to 45°C)
Operating Humidity	10% to 90% (noncondensing)
Latency	Less than 1 µs
