Creating a local mirroring group
Step Command Remarks
1. Enter system view.
system-view
N/A
2. Create a local mirroring
group.
mirroring-group
group-id
local
By default, no local mirroring
group exists.
Configuring source ports for the local mirroring group
To configure source ports for a local mirroring group, use one of the following methods:
• Assign a list of source ports to the mirroring group in system view.
• Assign a port to the mirroring group as a source port in interface view.
To assign multiple ports to the mirroring group as source ports in interface view, repeat the
operation.
Configuration restrictions and guidelines
When you configure source ports for a local mirroring group, follow these restrictions and guidelines:
• A mirroring group can contain multiple source ports.
• A port can act as a source port for multiple mirroring groups.
• A source port cannot be used as a reflector port, egress port, or monitor port.
• When you configure a TRILL access port as a source port, only non-TRILL-encapsulated
packets can be mirrored. Other packets are dropped.
• When you configure a TRILL trunk port as a source port, only TRILL-encapsulated packets can
be mirrored. Other packets are dropped.
• When you configure a TRILL hybrid port as a source port, both TRILL-encapsulated and
non-TRILL-encapsulated packets can be mirrored.
Configuring source ports in system view
Step Command Remarks
1. Enter system view.
system-view
N/A
2. Configure source ports for
the specified local mirroring
group.
mirroring-group
group-id
mirroring-port
interface-list
{
both
|
inbound
|
outbound
}
By default, no source port is
configured for a local mirroring
group.
Configuring source ports in interface view
Step Command Remarks
1. Enter system view.
system-view
N/A
2. Enter interface view.
interface
interface-type
interface-number
N/A
3. Configure the port as a
source port for the specified
local mirroring group.
mirroring-group
group-id
mirroring-port
{
both
|
inbound
|
outbound
}
By default, a port does not act as
a source port for any local
mirroring group.
