HPE FlexFabric 5700 Series User Manual

52
Tasks at a glance
The PTP standard is IEEE 1588 version 2:
(Required.) Specifying a clock node type
(Optiona
l.) Specifying a PTP domain
(Optiona
l.) Configuring an OC to operate only as a member clock
(Optiona
l.) Configuring the role of a PTP port
(Optional.) Configuring the mode for carrying timestamps
(Optiona
l.) Specifying a delay measurement mechanism for a BC or an OC
(Optiona
l.) Configuring the port type for a TC+OC
(Optiona
l.) Setting the interval for sending announce messages
(Optiona
l.) Setting the interval for sending Pdelay_Req messages
(Optiona
l.) Setting the interval for sending Sync messages
(Optiona
l.) Setting the minimum interval for sending Delay_Req messages
(Optional.) Configuring the MAC address for non-pdelay messages
(Optiona
l.) Specifying the protocol for encapsulating PTP messages as UDP (IPv4)
(Optiona
l.) Specifying the source IP address for UDP packets
(Optiona
l.) Setting the delay correction value
(Optiona
l.) Setting the cumulative offset between the UTC and TAI
(Optiona
l.) Setting the correction date of the UTC
(Optiona
l.) Configuring the parameters of the BITS clock
(Optional.) Configuring a priority of the clock
(Optiona
l.) Specifying the system time source as PTP
(Req
uired.) Enabling PTP on a port
The PTP standard is IEEE 802.1AS (802.1AS):
(Required.) Specifying a clock node type
(Optional.) Specifying a PTP domain
(Optiona
l.) Configuring an OC to operate only as a member clock
(Optiona
l.) Configuring the role of a PTP port
(Optiona
l.) Configuring the port type for a TC+OC
(Optiona
l.) Setting the interval for sending announce messages
(Optiona
l.) Setting the interval for sending Pdelay_Req messages
(Optiona
l.) Setting the interval for sending Sync messages
(Optiona
l.) Setting the minimum interval for sending Delay_Req messages
(Optiona
l.) Setting the delay correction value
(Optiona
l.) Setting the cumulative offset between the UTC and TAI
(Optiona
l.) Setting the correction date of the UTC
(Optional.) Configuring the parameters of the BITS clock
(Optiona
l.) Configuring a priority of the clock
(Optiona
l.) Specifying the system time source as PTP
(Req
uired.) Enabling PTP on a port

HPE FlexFabric 5700 Series Specifications

General

Product Line	HPE FlexFabric
Model	5700 Series
Power Supply	Redundant power supply options
Layer Support	Layer 2/3
Management	HPE Intelligent Management Center (IMC), CLI, SNMP
Routing Protocol	RIP, OSPF, BGP, IS-IS
Features	Virtualization
Compliant Standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1w, IEEE 802.1s, IEEE 802.3ad, IEEE 802.3ae
Operating Temperature	32°F to 113°F (0°C to 45°C)
Operating Humidity	10% to 90% (noncondensing)
Latency	Less than 1 µs
