HPE ProLiant DL180

2 Health LED
Solid green = Normal
Flashing green (1 flash per second) = iLO is rebooting
Flashing amber = System degraded
Flashing red (1 flash per second) = System critical
If the health LED indicates a degraded or critical state,
review the system IML ("Integrated Management Log" on
page 129) or use iLO ("HPE iLO" on page 127) to review the
system health status.
3 NIC status LED
Solid green = Link to network
Flashing green (1 flash per second) = Network active
Off = No network activity
4 Power On/Standby
button and system power
LED
Solid green = System on
Flashing green (1 flash per second) = Performing power on
sequence
Solid amber = System in standby
Off = No power present
If the system power LED is off, verify the following
conditions:
• The facility power is present.
• The power supply is installed and is working correctly.
• The power cord is attached and is connected to a power
source.
• The front I/O cable is connected.
When all four LEDs described in this table flash simultaneously, a power fault has occurred. For more
information, see Power fault LEDs.
UID button functionality
The UID button can be used to display the Server Health Summary when the server will not power on.
For more information, see the latest HPE iLO 5 User Guide on the Hewlett Packard Enterprise website.
Power fault LEDs
The following table provides a list of power fault LEDs, and the subsystems that are affected. Not all
power faults are used by all servers.
Subsystem LED behavior
System board 1 flash
Processor 2 flashes
Memory 3 flashes
Riser board PCIe slots 4 flashes
Table Continued
