d. Connect the optical drive cable.
11. Connect the iLO service port cable to system board.
12. Install the air baffle.
13. Install the access panel.
14. Install the server into the rack.
15. Connect all peripheral cables to the server.
16. Connect each power cord to the server.
17. Connect each power cord to the power source.
18. Power up the server on page 43.
19. If removed, install the front bezel.
The installation is complete.
Installing the optical drive or NVMe drives in the SFF chassis
Prerequisites
Before you perform this procedure, make sure that you have the following items available:
• Optical drive option
• One of the following:
◦ Optical drive cage option
◦ NVMe-optical drive cage option
• T-15 Torx screwdriver
74 Hardware options installation
