HPE ProLiant DL180

9. Install the access panel.
10. Install the server into the rack.
11. Connect all peripheral cables to the server.
12. Connect each power cord to the server.
13. Connect each power cord to the power source.
14. Power up the server on page 43.
The installation is complete.
Expansion board options
PCIe slot guidelines for network cards and PCIe workload accelerator
options
The following table shows the PCIe riser board slots supported with the network cards and the PCIe
workload accelerator options of the server.
Component Slot 1 Slot 2 Slot 3 Slot 4 Slot 5 Slot 6
HPE Ethernet networking card Yes Yes Yes Yes No Yes
HPE Ethernet 4-port
networking card
Yes Yes Yes No No Yes
HPE 10 Gb networking card
(Supported up to max 3 pcs)
Yes No No Yes Yes No
Table Continued
Hardware options installation 95
