b. Install the rear 2-bay SFF drive cage, and then install the screws.
10. Connect the Mini-SAS cable or the SATA and the SATA management port cables.
11. Connect GPU and rear 2-bay SFF power cable.
12. Install the drives.
13. Install the air baffle.
14. Install the access panel.
15. Install the server into the rack.
16. Connect all peripheral cables to the server.
17. Connect each power cord to the server.
18. Connect each power cord to the power source.
19. Power up the server on page 43.
64 Hardware options installation
