Shenzhen Hpmont Technology Co., Ltd Appendix C Communication Protocol
HD30 Series Inverters User Manual 191
Definition of virtual terminal control setting word:
Control word (Bit) Value Definition
Bit0
0 DO1 output is disabled
1 DO1 output is enabled
Bit1
0 DO2 output is disabled
1 DO2 output is enabled
Bit2
0 RLY1output is disabled
1 RLY1 output is enabled
Bit3
0 RLY2 output is disabled
1 RLY2 output is enabled
Bit4
0 RLY3 output is disabled
1 RLY3 output is enabled
Bit5
0 RLY4 output is disabled
1 RLY4 output is enabled
Bit6
0 RLY5 output is disabled
1 RLY5 output is enabled
Bit7
0 RLY6 output is disabled
1 RLY6 output is enabled
Bit8
0 RLY7 output is disabled
1 RLY7 output is enabled
Bit9
0 RLY8 output is disabled
1 RLY8 output is enabled
Bit10
0 RLY9 output is disabled
1 RLY9 output is enabled
Bit11
0 RLY10 output is disabled
1 RLY10 output is enabled
Bit12Bit15 Reversed Reversed
2) Status parameter
Inverter status parameter intergroup index is as following table:
Register
address
Parameter name
Register
address
Parameter name
0x3300 Inverter’s series 0x3311 Setting speed
0x3301 Software version of the U1 0x3312 Running speed
0x3303
Special software version of the U1
0x3313
Three-phase power input phase
sequence
0x3305 Software version of the display panel 0x3314 Output voltage
0x3306 Custom series No. 0x3315 Output current
0x3307
Units: the present motor
0: Motor 1
1: Motor 2
0x3317 Output torque
0x3318 Output power
0x3319 DC bus voltage
0x331A Input voltage of display panel of
C
