hpmont HD30 Series User Manual

Appendix C Communication Protocol Shenzhen Hpmont Technology Co., Ltd
―192― HD30 Series Inverters User Manual
Register
address
Parameter name
Register
address
Parameter name
Tens: control modes
0: V/f control without PG
1: Reversed
2: Vector control without PG
potentiometer
0x331B AI1 input voltage
0x331C AI1 input voltage (after disposal)
0x331D AI2 input voltage
0x331E AI2 input voltage (after disposal)
0x3308 Inverter’s rated current 0x331F AI3 input voltage
0x3309 Inverter’s extension function 0x3320 AI3 input voltage (after disposal)
0x330A
Units:
Bit0: Inverter fault
Bit1: Run/stop
Bit2: Forward/reverse
Bit3: Zero speed to run
Tens:
Bit0&1: Acc./ Dec./ constant
Bit2: Reversed
Bit3: DC braking (includes starting DC
braking and stop DC braking)
Hundreds:
Bit0: Parameter auto-tuning
Bit1: Reversed
Bit2: Speed limitation
Bit3: Reversed
Thousands:
Bit0: Stall overvoltage
Bit1: Stall overcurrent
Bit2: Reversed
Bit3: Reversed
0x3321 AI4 input voltage
0x3322 AI4 input voltage (after disposal)
0x3323 DI6 terminal pulse input frequency
0x3324 AO1 output
0x3325 AO2 output
0x3326 High-speed output pulse frequency
0x3327 Heatsink temperature
0x332C Process PID reference
0x332D Process PID feedback
0x332E Process PID error
0x332F Process PID integral
0x3330 Process PID output
0x3331 External counting value
0x3332 Input terminal status
0x3333 Output terminal status
0x3334 MODBUS communication status
0x3335 Actual length
0x3336 Total length
0x3337 Total time at power on (hour)
0x3338 Total time at running (hour)
0x330B Master setting frequency source 0x3339 High byte of motor total energy
0x330C Master setting frequency 0x333A Low byte of motor total energy
0x330D Auxiliary setting frequency 0x333B High byte of this running energy
0x330E Setting frequency 0x333C Low byte of this running energy
0x330F Reference frquency (after Acc./Dec.) 0x333D The present fault code
0x3310 Output frequency 0x3345 The current moment (hours)
For instance: The register address of function parameter F03.02 is 0x0302, and that of function
parameter F16.01 is 0x1001.
