FusionModule800 Smart Small Data Center
Installation Guide (Six Fans)
3 Hardware Installation
Copyright © Huawei Technologies Co., Ltd.
168
Figure 3-193 Detector positions
(1) Water detector
Figure 3-194 Water sensor
(1) Water detector
(2) Conversion cable end A,
connected to the water detector
(3) Conversion
cable
