Huawei FusionModule800 Installation Guide

FusionModule800 Smart Small Data Center
Installation Guide (Six Fans)
5 Checking After Installation
Issue 10 (2019-12-20)
Copyright © Huawei Technologies Co., Ltd.
229
Table 5-3 Pipe connection checklist
Check That
Check Result
Pipe connectors are correct. The refrigerant
pipe tilts and has supports.
□ Passed □ Failed
The hose clamps and cable ties of the
drainpipe are secured.
□ Passed □ Failed
The refrigerant pipe and water pipe are
wrapped with thermal insulation foam.
□ Passed □ Failed
All pipes have been checked for leaks.
□ Passed □ Failed
Water pipe joints have been sealed by
sealant.
□ Passed □ Failed
The pipes are not bent by a large angle.
□ Passed □ Failed
Stop valves for the gas pipe and liquid pipe
of the outdoor unit are open.
□ Passed □ Failed
Cable holes in walls are sealed.
□ Passed □ Failed
Cabinet Installation Check
Table 5-4 Cabinet installation check items
No.
Check That
Check Result
1
The cabinet layout position is consistent with the
equipment room layout diagram.
□ Passed □ Failed
2
All bolts are tightened, especially the bolts used for
electric connection. Flat washers and spring washers are
installed properly.
□ Passed □ Failed
3
The cabinet is clean and free of dust and other materials.
□ Passed □ Failed
4
The cabinet is clear and complies with dustproof
requirements.
□ Passed □ Failed
5
The paint on the cabinet exterior is intact. Promptly
repaint the cabinet exterior if necessary to prevent
corrosion.
□ Passed □ Failed
6
The cabinet door and lock work properly.
□ Passed □ Failed
7
All labels are correct, clear, and complete.
□ Passed □ Failed
8
The cabinet has no waste tape, cable ties, paper, or
packing materials around it.
□ Passed □ Failed
9
All components are properly installed and no component
□ Passed □ Failed
