Huawei FusionModule800 Installation Guide

FusionModule800 Smart Small Data Center
Installation Guide (Six Fans)
5 Checking After Installation
Issue 10 (2019-12-20)
Copyright © Huawei Technologies Co., Ltd.
230
No.
Check That
Check Result
is left onsite.
10
Block empty cable holes using plugs or lids.
□ Passed □ Failed
Cable Installation Check
Table 5-5 Cable installation check items
No.
Check That
Check Result
1
All cable joints are secured properly, especially the cable
joints between network cables.
□ Passed □ Failed
2
Exposed parts near the wiring terminals and lugs are
wrapped in PVC insulation tape or heat shrinking tubing.
□ Passed □ Failed
3
The flat washers and spring washers of all wiring
terminals are securely installed.
□ Passed □ Failed
4
Cables are bound neatly and cable ties are secured evenly
and properly.
□ Passed □ Failed
5
Routed cables should be convenient for future
maintenance and expansion.
□ Passed □ Failed
6
All labels at the cable ends are clear.
□ Passed □ Failed
7
The excess section of a cable strip is cut evenly.
□ Passed □ Failed
8
There are no unnecessary adhesive tape or cable ties on
cables.
□ Passed □ Failed
Electrical Installation Check
Table 5-6 Electric installation check items
No.
Check That
Check Result
1
All ground cables are copper cables. Cable diameters are
correct. No switches or fuses are installed on the cables
and no short circuit occurs.
□ Passed □ Failed
2
The ground cable, AC power cables, and internal cables
are correctly connected and screws are secured. No short
circuit occurs during power input or output.
□ Passed □ Failed
3
The smart cooling product input voltage is within the
range of rated voltage ±10%, and the input frequency is
within the range of rated frequency ±3 Hz.
□ Passed □ Failed
4
The length of ground cables and power cables is correct.
□ Passed □ Failed
