Huawei FusionModule800 Installation Guide

FusionModule800 Smart Small Data Center
Installation Guide (Six Fans)
6 Power-On Commissioning
Issue 10 (2019-12-20)
Copyright © Huawei Technologies Co., Ltd.
270
Context
Convert the components that cause partial resistance loss such as elbows into the length
equivalent to that of straight pipes, and add the equivalent length to the length of the straight
pipe between the indoor and outdoor units to obtain the total one-way pipe length (L). L
should be less than or equal to 60 meters. If L exceeds 60 meters, contact Huawei technical
support.
Table 6-21 Equivalent length of pipe assemblies
Pipe Outer Diameter
90° Bend
180° Bend
5/8 inch (15.88 mm)
0.3 meter
0.6 meter
3/8 inch (9.52 mm)
0.2 meter
0.4 meter
Table 6-22 lists how to calculate the amount of refrigerant to be charged onsite.
Table 6-22 Calculating the amount of refrigerant to be charged onsite
Type
NetCol5000-A011
One-way pipe length (m)
0 < L ≤ 30
30 < L ≤ 60
Amount of added
refrigerant (kg)
NetCol500-A018
0
(L – 30) x 0.05
NetCol500-A020
0
(L – 30) x 0.1
Refrigerant R410A from name brands such as Daikin are recommended.
Wear antifreeze gloves when performing refrigerant related operations.
Following are the tools used for commissioning and refrigerant charging:

Charging tools: pressure gauge (measuring range ≥ 4.0 MPa), leather hose (withstanding
a pressure of at least 4.5 MPa), vacuum pump

Measurement tools: electric balance

Protective tools: insulation gloves, antifreeze gloves, and insulation shoes

Other tools: flashlight
Table 3-3 lists the mapping between the saturation pressure and the temperature.
