FusionModule800 Smart Small Data Center
Installation Guide (Six Fans)
Copyright © Huawei Technologies Co., Ltd.
Record the PAD cable route because you need to bind the PAD cable along the original route
in subsequent installation.
Figure 3-10 Removing the PAD cable
Step 3 Lift the cabinet door until it is separate from the hinge, and remove the front door, as shown
in Figure 3-11.
