FusionModule800 Smart Small Data Center
Installation Guide (Six Fans)
3 Hardware Installation
Copyright © Huawei Technologies Co., Ltd.
35
The cabinet front door is heavy. Arrange at least two persons to carry the door.
Before removing the cabinet door, disconnect the ground cable between the cabinet door
and the cabinet.
Figure 3-11 Removing a cabinet door
Step 4 (Optional) Unscrew the air director from the Converged Cabinet and pull out the air director,
as shown in Figure 3-12.
