FusionModule800 Smart Small Data Center
Installation Guide (Six Fans)
Copyright © Huawei Technologies Co., Ltd.
Align the sealing plate fasteners with those in front of the appropriate sealing frame.
Obtain the sealing plate fasteners from the Converged Cabinet fitting bag.
Figure 3-18 Installing sealing plate fasteners on an end cabinet
Step 4 Install an aisle side sealing plate on the end cabinet side towards the aisle exterior using the
screws removed in Step 1.
