FusionModule800 Smart Small Data Center
Installation Guide (Six Fans)
Copyright © Huawei Technologies Co., Ltd.
Procedure
Step 1 Remove the side panel from the IT cabinet, as shown in Figure 3-20.
Set the removed materials aside for they will be used in subsequent installation steps.
Figure 3-20 Removing side panels from an IT cabinet
Step 2 Install the removed side panels on the side of end IT cabinets facing the aisle exterior by
referring to Step 1.
After adjusting the positions of IT cabinet side panels, ensure that side panels are installed on
the side of end IT cabinets facing the aisle exterior.
----End
