Huawei IDS1000-A - Replacing a Ventilation Vent Air Filter

IDS1000-A Air-Cooled Container Data Center
All-in-One Maintenance Guide
5 Parts Replacement
Issue 01 (2016-01-10)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
88
No.
Item
12
LCD
Table 5-2 Parts that can be replaced for a 35 kW precision air conditioner
No.
Item
1
Air filter
2
Indoor fan
3
Compressor
4
Compressor driver
5
Condensate pump
6
Humidifier cylinder
7
Electric heater
5.2.5 Replacing a Ventilation Vent Air Filter
Prerequisites

An air filter needs to be replaced.

A spare air filter of the same model is available and functional.
Impact on the System
None
Preparations
Tool: flat-head screwdriver, step ladder, brush
Material: spare air filters
Documents required: none
Skill requirement: cooling engineer
Procedure
Step 1 Remove the air filter using the flat-head screwdriver, as shown in Figure 5-10.
